Edge AI on FPGA — Potato Chip Inspection
ONE AI generates optimized architectures that make hardware secondary. This benchmark deploys a quality inspection model on a decade-old Altera MAX® 10 FPGA and compares it against an Nvidia Jetson Orin Nano running a conventional network.
Full results published in the Altera × ONE WARE Whitepaper.
The Task
Detect burn marks and defects on potato chips in real time on a fast production line — under strict limits on latency, power, and cost.
Good
Defective
Results
| Metric | MAX® 10 + ONE AI | Jetson Orin Nano (VGG19) | Improvement |
|---|---|---|---|
| Accuracy | 99.5 % (INT8) | 88 % (FP32) | 24× fewer errors |
| Power | 0.5 W | 10 W | 20× lower |
| Latency | 0.086 ms | 42 ms | 488× faster |
| Cost | €45 | €250 | 6× cheaper |
| Throughput | 1,736 FPS | 24 FPS | 72× higher |
| Footprint | 11×11 mm | 70×45 mm | 26× smaller |
Why It Works
Optimized Architecture
ONE AI generated a network with only 6,750 parameters and 0.0175 GOPs — compared to VGG19's 127 million parameters and 25 GOPs. The result: higher accuracy with a fraction of the compute.
Quantization-Aware Training
Training directly in INT8 preserves accuracy during quantization — a critical step for FPGA deployment where every bit matters.
HDL Deployment
The optimized model compiles into RTL/HDL and runs natively on the FPGA fabric. No runtime overhead, deterministic microsecond latency, and seamless integration with existing control logic.
Takeaway
Even with decade-old FPGA hardware, an optimized ONE AI model outperforms a modern GPU across every dimension — accuracy, speed, power, cost, and size. The bottleneck in edge AI is not the hardware — it's the model design.
